carbon fiber
Bidirectional Carbon Fabric
|
No. |
Reinforcement Yarn |
Weave
Pattern
|
Fiber Count(10mm) |
Weight
(G/sQ.M)
|
Thickness
(mm)
|
Width
(mm)
|
||
|
Warp |
Weft |
Warp |
Weft |
|||||
| F1KP120 | 1k |
1k |
Piain | 9 | 9 | 120 | 0.12 | 100-1500 |
|
F1KT120 |
1k |
1k |
Twill | 9 | 9 | 120 |
0.12 |
100-1500 |
|
F1KP140 |
1k |
1k |
Piain |
10.5 |
10.5 |
140 | 0.14 |
100-1500 |
|
F1KT140 |
1k |
1k |
Twill |
10.5 |
10.5 |
140 | 0.14 |
100-1500 |
|
F3KP160 |
3K |
3K |
Piain |
4 | 4 | 160 | 0.16 |
100-1500 |
|
F3KT160 |
3K |
3K |
Twill |
4 | 4 | 160 | 0.16 |
100-1500 |
|
F3KP180 |
3K |
3K |
Piain |
4.5 |
4.5 |
180 | 0.18 |
100-1500 |
|
F3KT180 |
3K |
3K |
Twill |
4.5 |
4.5 |
180 | 0.18 |
100-1500 |
|
F3KP200 |
3K |
3K |
Piain |
5 | 5 | 200 | 0.20 |
100-1500 |
|
F3KT200 |
3K |
3K |
Twill |
5 | 5 | 200 | 0.20 |
100-1500 |
|
F3KP220 |
3K |
3K |
Piain |
5.5 |
5.5 |
220 | 0.22 |
100-1500 |
|
F3KT220 |
3K |
3K |
Twill |
5.5 |
5.5 |
220 | 0.22 |
100-1500 |
|
F3KP240 |
3K |
3K |
Piain |
6 | 6 | 240 | 0.24 |
100-1500 |
|
F3KT240 |
3K |
3K |
Twill |
6 | 6 | 240 | 0.24 |
100-1500 |
|
F6KP280 |
6K |
6K |
Piain |
3.5 |
3.5 |
280 | 0.28 |
100-1500 |
|
F6KT280 |
6K |
6K |
Twill |
3.5 |
3.5 |
280 | 0.28 |
100-1500 |
|
F6KP320 |
6K |
6K |
Piain |
4 | 4 | 320 | 0.32 |
100-1500 |
|
F6KT320 |
6K |
6K |
Twill |
4 | 4 | 320 | 0.32 |
100-1500 |
|
F6KP360 |
6K |
6K |
Piain |
4.5 |
4.5 |
360 | 0.36 |
100-1500 |
|
F6KT360 |
6K |
6K |
Twill |
4.5 |
4.5 |
360 | 0.36 |
100-1500 |
|
F12KP320 |
12K |
12K |
Piain |
2 | 2 | 320 | 0.32 |
100-1500 |
|
F12KT329 |
12K |
12K |
Twill |
2 | 2 | 320 | 0.32 |
100-1500 |
|
F12KP409 |
12K |
12K |
Piain |
2.5 |
2.5 |
400 | 0.40 |
100-1500 |
|
F12KT40G |
12K |
12K |
Twill |
2.5 |
2.5 |
400 | 0.40 |
100-1500 |
|
F12KP489 |
12K |
12K |
Piain |
3 | 3 | 480 | 0.48 |
100-1500 |
|
F12KT480 |
12K |
12K |
Twill |
3 | 3 | 480 | 0.48 |
100-1500 |
|
F12KP569 |
12K |
12K |
Piain |
3.5 |
3.5 |
560 | 0.56 |
100-1500 |
|
F12KT569 |
12K |
12K |
Twill |
3.5 |
3.5 |
560 | 0.56 |
100-1500 |
|
F12KP649 |
12K |
12K |
Piain |
4 | 4 | 640 | 0.64 |
100-1500 |
|
F12KT64d |
12K |
12K |
Twill |
4 | 4 | 640 | 0.64 |
100-1500 |
 |
 |
 |
 |
