Process Continuous filament Winding Process

CONTINUOUS FILAMENT WINDING


Machinery

COMPLETE GRP PIPE CONTINUOUS FILAMENT WINDING PRODUCTION LINE



 Product Specification

 Max. Production Speed

 Avg. Production Speed

 DN300-400

 36m/h

 28m/h

 DN450-800

 32m/h

 24m/h

 DN900-1200

 24m/h

 20m/h

 DN1400-1600

 16m/h

 14m/h

 DN1800-2000

 12m/h

 10m/h

 DN2200-2600

 10m/h

 9 m/h

 DN2800-3000

 8m/h

 7 m/h



Materials

 Base Materials (Resin)

 Reinforcing Materials (Fiber Glass Raw Materials)

 Accessory materials

 Accessorytools

 Liner Resin: ISO resin/ Vinlyester Resin

 Assembled Roving: 2400tex Chop Roving For Filament Winding

 Polyester film: 23um-50mm

 Diamond Saw Blade

 Structure Resin: Ort-resin

 Direct roving: 1200 tex, 2400 tex, 4800 tex

 Polyester Netting

 Rubber Seal Ring

 Hardener: MEKP

 Surface tissue/veil: 27gsm-45mm



 Accelerant
